- Basic module equipped with:
– Variable DC power supply (-10v to 0 and 0 to +10v)
- High-Pressure process module equipped with:
- Air storage tank and electrical wind pump
- Two pressure gage and industrial mano-meter
- MPXV2200DP sensor ( accurate high-pressure sensor)
- Low-pressure process module equipped with:
- Two kind of pressure sensor in kilo-pascal range
- Medical mano-meter
- A source to generate low-pressure gas
- Bridge amplifier module in order to get acquainted with strain-gauge and basic training for instrumentation amplifiers
- Set-point Generator module in order to test and adjusting of desired point adjust in control process
- Signal conditioning module in order to prepare the sensor’s signal for use in control loop
- PID controller module in order to analog control of different processes
- Isolated driver module
- Data Acquisition module in order to monitoring, sampling and controlling the different systems (connectable to PC with RAYANNIK software and controllable by MATLAB with special RAYANNIK library)
